ECG
|
|
|
Input
|
3/5 wire ECG cable
|
|
Lead section
|
I II III aVR, aVL, aVF, V
|
|
Gain selection
|
*0.25, *0.5, *1, *1.2
|
|
Sweep speed
|
6.25mm/s, 12.5mm/s, 25mm/s, 50mm/s
|
|
Heart rate range
|
15-30bpm
|
|
Calibration
|
±1mv
|
|
Accuracy
|
±1bpm or ±1% (select the bigger data)
|
|
NIBP
|
|
|
Test method
|
Oscillometer
|
|
Philosophy
|
Adult, Pediatric and Neonate
|
|
Measurement type
|
Systolic Diastolic Mean
|
|
Measurement parameter
|
Automatic, Continuous measurement
|
|
Measurement method Manual
|
mmHg or ±2%
|
|
SPO2
|
|
|
Display Type
|
Waveform, Data
|
|
Measurement range
|
0-100%
|
|
Accuracy
|
±3% (between 70%-100%)
|
|
Pulse rate range
|
20-300bpm
|
|
Accuracy
|
±1bpm or ±2% (select the bigger data)
|
|
Resolution
|
1bpm
|
|
2-Temperature (Rectal & Surface)
|
|
|
Number of channels
|
2 channels
|
|
Measurement range
|
0-50℃
|
|
Accuracy
|
±0.2℃
|
|
Display
|
T1, T2, ☒T
|
|
Unit
|
ºC/ºF selection
|
|
Refresh cycle
|
1s-2s
|
|
Respiration (Impedance & Nasal Tube)
|
|
|
Measurement type
|
0-150rpm
|
|
Accuracy
|
±1bm or ±5%, select the bigger data
|
|
Resolution
|
1rpm
|
|
Packing Information
|
|
|
Packing size
|
33*33*28cm
|
|
N.W.
|
4kg
|
|
G.W.
|
5kg
|
